Hi13-DCS 4G LTE Mobile Signal Booster
This high quality mobile signal booster is great for those who only want to receive great 4G voice signal within their home, office or business. It's suitable for all Irish mobile networks and is extremely easy to install.
Networks : DCS/ LTE 1800
Coverage : up to 300 - 500 square meters
Max.Gain : 65 dB
- 5 bar guarantee
- Smart LCD & auto set up
- Fully CE RED Certified
Enjoy seamless mobile signal reception in your home or office with HiBoost Hi13-DCS 4G LTE booster!
Specification:
| Working Bands |
1800 MHz |
|---|---|
| UL Frequency Range |
1710-1785 MHz |
| DL Frequency Range |
1805-1880 MHz |
| Supported Standards |
DCS/ LTE |
| V.S.W.R |
Typical≤2 |
| Maximum Gain |
65 db |
| MGC (Step Attenuation) |
≥ 31 db/ 1 db step |
| Intelligent AGC |
ALC ≥42dB |
| Gain Flatness |
Typical≤5dB (p-p) |
| Noise Figure @ Max. System Gain |
Typical≤5dB |
| Group Delay |
≤1μs |
| Frequency Stability |
≤0.01ppm |
| Power Supply |
Input AC 90~240 V, 50/60 Hz, Output DC 5V/3A |
| Power Consumption |
≤5W |
| Impedance |
50 ohm |
| LCD Display |
Frequency, Gain, Output Power, ALC, ISO indicators |
| I/O port |
N-Female |
| Dimensions |
120*155*34 mm/ 4.7*6.1*1.3 inch |
| Booster Weight |
0.7KG/ ≤1.5 lbs |
| Booster Kit Weight |
3.15 KG |
| Operating Temperature |
-10ºC~+55ºC |
| Storage Temperature |
-10ºC~+80ºC |
| Relative Humidity |
5% – 95% |
| Barometric Pressure |
55 kPa -106 kPa |
| Environment Condition |
IP40 |
Whats included:
Every HiBoost solution comes carefully arranged in a full kit with all the installation components.
HiBoost Hi13-DCS standard kit includes:
- Mobile signal booster
- Outdoor panel antenna
- Antenna
- 50ft (15.2 m) HiBoost 200 cable
- 5V/ 3A, AC/DC power supply
- Power Plug
